What a compact control room costs and what moves the price

Most enquiries I see open with the same question: what does a control room cost? The honest answer begins with how many people sit in it and how many signals pass through it. A two-seat room for a streaming team is a different job from a six-seat gallery with a producer, a vision mixer, a graphics operator and a replay position.

Floor area matters less than you might expect. What drives the work is the count of sources, outputs, monitors and operator positions, because each one needs a feed, a cable, a rack space and a place on the intercom. We ask for that list first, even if it is rough, since everything else in the quote hangs from it.

A small fit-out for a venue that streams a few events a month usually sits at the lower end of our range. A permanent room for a team that goes live several times a week sits well above it, mainly because it needs more resilience built in.

• Number of operator seats
• Number of camera and graphics sources
• Number of outputs and monitors
• How often the room will be used

Callum, our systems engineer, builds the racks, and he is the first to say that the visible equipment is the smaller part of the labour. Cable runs are measured, labelled and dressed, and each end is tested before anything is powered up. A tidy rack takes longer to build than a hasty one, and it is the reason a fault can be found in minutes rather than an hour.

Distance changes the price too. A room next to the studio floor needs short runs. A room two floors away, or in another building, needs longer cable, conduit or fibre, and sometimes the venue's own installer has to be involved.

We list cabling and labour as separate lines in a written quotation, so you can see how much of the figure is material and how much is careful workmanship. Rushing either of them tends to cost more later in faults and rework.

The monitor wall is the part clients picture first, and it is also where prices spread widely. A wall of six screens fed by a simple multiviewer is modest. A wall that shows every source, the programme output, the preview, audio meters and a clock on dedicated displays needs more screens, more processing and a stronger frame to hold them.

Screen quality is a choice with a clear trade-off. Operators who judge colour or focus need better panels than a team that only needs to see that a picture is present. We ask what each seat has to judge and recommend accordingly, not by default.

Ergonomics belong here as well. Viewing distance, angle and glare decide whether an operator is comfortable at hour four of a long show, and getting that right at the planning stage costs little compared with moving a wall afterwards.

• Screen count and panel quality
• Multiviewer capacity
• Mounting frame and viewing distance

Intercom is easy to leave off a first budget, and it is among the first things a live team misses. A show runs on clear short instructions between producer, mixer and camera operators, so the system has to be dependable and easy to hear. A basic wired panel set suits a small room. Wireless belt packs, larger channel counts or links to remote crew add cost.

Audio monitoring, tally lights and a reliable clock sit in the same category. Each is a small line on its own, but together they can account for a noticeable share of the total, and leaving them out usually means a second visit.

When we plan a room we write these items into the first draft of the quote, not into an optional extras list at the end, so the first figure you see is close to the figure you will pay.

There is more than one way to pay for a room, and the right one depends on how settled your plans are. A full build is quoted as a written fixed figure for the agreed scope, which suits teams who know what they need. If your needs are still forming, we can start with a smaller first phase, run shows in it, and add to it once you know what the team actually uses.

Some clients prefer to rent a portable deck while the permanent room is built, so shows continue without a gap. That is priced separately under our rental service and agreed in the same quotation.

Ordering works the way it does for all our work: you write to us through the contact page, we reply with a written quotation, you confirm it, and we invoice for payment by bank transfer. Changes to scope after confirmation are written down and priced before work begins.

• Fixed figure for an agreed scope
• Phased build in stages
• Rental deck while the room is built

A good quote starts with a short, honest brief. Send us the room's location and rough dimensions, the sources you expect to use, the number of people who will work in it, and the kind of shows it will carry. Photographs of the space help, as does a note of anything in the building that cannot be moved or drilled.

Tell us your budget range if you have one. It will not make us inflate the figure. It lets us propose a layout that fits, and say plainly where a saving would cost you in reliability or comfort.

If you are unsure about any item, say so. We would rather talk it through on the phone than guess, and a ten-minute conversation often removes a whole line from the quote.
